Model of the Paddle Gear of the Lock at Flushing
From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.
About this work
Model of a winch for operating the sluices of lock gates, on a baseboard. The winch stands on four legs. With a crank on both sides, a gear mechanism inside is driven, which moves a rack with round pins instead of teeth up and down. A toothed wheel with a pawl on one side prevents the winch from running back. Scale 1:3 (derived).
Rijksmuseum, Amsterdam’s own descriptionSubjects
Credit lineModel of the Paddle Gear of the Lock at Flushing. 1837. Rijkswerf Vlissingen. Rijksmuseum, Amsterdam. Public domain.
