Model of a Prototype Dispatch Vessel
Public domain

Model of a Prototype Dispatch Vessel

anonymous · c. 1833 · iron (metal); rope; wood (plant material); brass (alloy)

From the collection of Rijksmuseum, Amsterdam. Free to download, adapt and use — no permission needed.

About this work

Model of a hand-powered catamaran. The two floats are connected at the ends by battens and each has a place for a driver. The propulsion mechanism consists of a single paddle wheel with counterweights, set in motion by hand cranks on each side. Both floats have a rudder, whose tillers are connected by a hinged rod; they are operated by a steering tackle running over pulleys.

Rijksmuseum, Amsterdam’s own description
Subjects
scale modeldemonstration model
Credit lineModel of a Prototype Dispatch Vessel. c. 1833. anonymous. Rijksmuseum, Amsterdam. Public domain.
